This article will explain the meaning of the status lights found on the Arris CM8200 Modem, the default NBN™ Connection Box for NBN™ HFC. These lights may help you quickly check on the status of your connection which may be useful when troubleshooting. If you still can’t get online after troubleshooting, please call your NBN Provider for further assistance.
Things to note
- Note that ONLINE, DOWNSTREAM and UPSTREAM lights will all FLASH briefly when the Connection Box is powered on. This is a self-test and no action is needed, just wait for the Connection Box to finish booting up.
- If both UPSTREAM and DOWNSTREAM lights are FLASHING but ONLINE light is OFF, there is no connection to the NBN™ network. Please call your NBN service provider for assistance.
- If both UPSTREAM and DOWNSTREAM lights are FLASHING and ONLINE light is ON, a firmware update is in progress. No action is needed - simply wait for the update to complete.
Status lights on the back
The UNI-D1 port on the back of the Connection Box has LINK lights to indicate cable connection to a computer or router.
- Green: Cable connection detected. If this light is off, try another CAT5e or CAT6 Ethernet cable.
- Yellow: Old CAT5 Ethernet cable is in use - this may not allow throughput of the full speed of your NBN™ HFC service. Please change it out for a CAT5e or CAT6 Ethernet cable.
Status lights on the front
POWER - Off = Connection Box has no power.
POWER - On = Connection Box has power.
DOWNSTREAM - Off = Connection Box has no power.
DOWNSTREAM - On = Successful downstream connection.
DOWNSTREAM - Flashing = Searching for downstream connection. If ONLINE light is on, firmware upgrade in progress.
UPSTREAM - Off = Still searching for downstream connection, or Connection Box has no power.
UPSTREAM - On = Successful upstream connection.
UPSTREAM - Flashing = Searching for upstream connection. If ONLINE light is on, firmware upgrade in progress.
ONLINE - Off = Connection Box is offline or has no power.
ONLINE - On = Connection Box is online and browsing should be possible.
ONLINE - Flashing = Downstream and upstream connection found; retrieving setup information from NBN.
